SKU: V11H923540DA

EB-800F

Best for digital signage in retail and public spaces. Ultra-short-throw Full HD laser projector with 5,000 lumens and 360-degree rotation.

  • Ultra-short-throw
  • Up to 130-inch display
  • 5,000 lumens

Features

Ultra-short-throw signage projector

Compact, unobtrusive design.

Up to 130-inch display

Full HD resolution, 5,000 lumen brightness and 3LCD technology

Fit and forget reliability

Low maintenance laser projector with a 5 year warranty

Easy installation

360 degree rotation with portrait projection support

Specifications

Projector Colour
White
Heat Dissipation
1244 BTUperhour
Loudspeaker
8 W
Loudspeaker Type
Stereo
Noise Level -Normal
36 dB (A)
Noise Level -Economy
27 dB (A)
Noise Level - Eco2
0
Options
Wireless LAN unit
Positioning
Ceiling Mounted
Power consumption -(Normal On-Mode)
293 W
Power consumption- (Eco On-Mode)
366 W
Power consumption -(Normal Peak-mode)
262 W
Power consumption -(Eco Peak-Mode)
0.5 W
Power consumption - (Energy saving standby)
194 W
Product Dimensions
458 x 375 x 209.5 mm (Width x Depth x Height)
Product Range
E9
Room Type / Application
Signage / Retail
Single Unit
ZN
Supply Voltage
220 V - 240 V, 50 Hz - 60 Hz
Supported Humidity - Operation (from)
20 %
Supported Humidity - Operation (to)
80 %
Supported Humidity - Storage (from)
10 %
Supported Humidity - Storage (to)
90 %
Supported Temperature - Operation (from)
0
Supported Temperature - Operation (to)
45
Supported Temperature - Storage (from)
-10 °C
Supported Temperature - Storage (to)
60 °C
TCO Certified
No
